Proctor Mould
Proctor Mould for standard & modified compaction testing of soils. Available in 100MM and 150MM diameter sizes. Used in geotechnical labs per IS/ASTM standards.
zoom_in
Proctor Mould
Proctor Mould for standard & modified compaction testing of soils. Available in 100MM and 150MM diameter sizes. Used in geotechnical labs per IS/ASTM standards.
Est. Lead Time
2-4 Days
Standard finish in stock. Custom fabrication adds 5 days.
Galvanized Finish
Mill Test Reports
Seismic Rated
Bulk Discounts
Product Overview
A Proctor Mould is a cylindrical metal mould used in the laboratory to determine the optimum moisture content and maximum dry density of soil through compaction tests. It is an essential apparatus for Standard Proctor (IS: 2720 Part 7) and Modified Proctor (IS: 2720 Part 8) compaction tests, widely used in civil and geotechnical engineering.
Available Sizes:
- 100MM dia – Used for Standard Proctor Compaction Test
- 150MM dia – Used for Modified / Heavy Compaction Test (2250cc volume)
Applications:
- Determination of optimum moisture content (OMC) of soil
- Determination of maximum dry density (MDD) of soil
- Quality control of compaction in road, dam, and foundation construction
- Subgrade and sub-base material testing
Features:
- Precision-machined steel body for accurate volume and dimensional tolerances
- Sturdy detachable collar and base plate for easy sample extraction
- Compatible with standard Proctor rammer and modified rammer
- Available in both 100MM and 150MM diameter as per IS/ASTM standards
- Durable finish for long service life in lab conditions
Safety Certification
verified_user
Certified Structural Grade
Verified by third-party lab
Our products undergo rigorous testing to ensure they meet and exceed industry safety standards for high-load applications.
