Cube Mould
GENERAL INFORMATION
Cube Mould as per international and Indian standards (BS, IS and ASTM). These cube moulds are available in different sizes. For the metric size cube mould, the faces are machined flat to +/-0.2mm accuracy and finished to within 0.2mm. For the inch size moulds, the faces are machined flat to +/-0.01 inched to within 0.01in. All cube moulds are supplied complete with the base plate.
Specification | Description |
---|---|
Size | 150 mm x 150 mm x 150 mm (6” x 6” x 6”) |
Material | Cast Iron / Mild Steel (MS) / Ductile Iron |
Finish | Machined surface with anti-rust coating (usually blue or black paint) |
Construction | 2-part or 3-part design, bolted or clamped |
Weight | Approx. 12–13 kg |
Surface Flatness | ±0.02 mm on each face |
Tolerances | ±0.2 mm as per IS:10086 or BS EN 12390-1 |
Identification | Embossed with size and standard (e.g., “150mm – IS”) |
AVAILABLE SIZES
- PIT 221A : Mould (Cast Iron – for Mortar) 50mm, Single Gang
- PIT 221B : Mould (Cast Iron – for Mortar) 50mm, Three Gang
- PIT 221C : Mould (Mild Steel – for Cement) 70.6mm, with Loose Base Plate
- PIT 221D : Mould (Cast Iron – for Concrete) 75mm Single Gang
- PIT 221E : Mould (Cast Iron – for Concrete) 100mm Light Weight
- PIT 221F : Mould (Cast Iron – for Concrete) 100mm Clamp Type (8.5 KG) Four-Part
- PIT 221H : Mould (Cast Iron – for Concrete) 150mm ISI Marked
- PIT 221I : Mould (Cast Iron -for Concrete) 150mm Clamp Type (16 KG) Four- Part
- PIT 221J : Mould (Cast Iron – for Concrete) 150mm Clamp Type (16 KG) Two-Part
-
Heavy-duty construction for durability
-
Perfect internal angles to ensure accurate cube geometry
-
Easy demolding via base plate separation or side-release bolts
-
Reusable after proper cleaning and oiling
-
Compatible with vibrating tables for compacting concrete
PTK-CM-01
IS 10086:1982
