Metacentric Height Apparatus
Metacentric height apparatus to determine stability of floating bodies and study metacentric height experimentally.
zoom_in
Metacentric Height Apparatus
Metacentric height apparatus to determine stability of floating bodies and study metacentric height experimentally.
Est. Lead Time
2-4 Days
Standard finish in stock. Custom fabrication adds 5 days.
Galvanized Finish
Mill Test Reports
Seismic Rated
Bulk Discounts
Product Overview
Description
A pontoon is allowed to float in a small tank having a transparent side. Removable steel strips placed in the model for the purpose of changing the weight of the model. Displacement of weight is measured with the help of a scale.
Technical Specification
By means of a pendulum (consisting of a weight suspended to a long pointer) the angle of tilt can be measured on a graduated arc.
For tilting the ship model, a cross bar with movable hanger is fixed on the model. Pendulum and graduated arc are suitably fixed at the center of the cross bar. A set of weights is supplied with the apparatus
